markgaq.blogg.se - Anatel wifi module v000310630

WE935B00 Single-Band Embedded Wi-Fi Module with integrted Chip antenna & MHF4 IPEX connector (Serial to Wi-Fi).

WM825B00 Single-Band Wi-Fi 802.11 b/g/n module with integrated chip antenna and MHF4 IPEX connector.

WM828CC6 Dual-Band Wi-Fi 802.11 ac/a/b/g/n, Bluetooth 4.2/BLE Module with integrated MHF4 IPEX connector.

Multi Protocol (Combo) (Wi-Fi + BT/BLE).

Maximum Performance (Hosted Wireless Modules).

A complete software driver support for Linux and all related collaterals will help the user to evaluate this hosted Wi-Fi module and integrate into their end system with substantial reduction in their RND efforts, resources, budget and supports faster time to market. The Kit comes with Multi-Protocol wifi+BT module Evaluation Board, a Micro USB to USB cable and a 2.4 & 5 GHz Rubber Duck Antenna with MHF4 IPEX connector cable. This Multi-Radio module evaluation board was used for performing FCC, CE and IC certification and the same can be used to perform the RF tests for any regional certifications like TELEC, KCC, Anatel, etc.

This WM828CC6 wireless LAN + Bluetooth classic & Bluetooth Low Energry Multi-band module along with other supporting passive components is mounted on the Evaluation board which is designed as SD card adapter to directly insert into various Microprocessor development platforms or Laptops without any extra connectors. The WM828CC6 Evaluation kit is a Wi-Fi plus BT & BLE combo evaluation platform for the WM828CC6 Dual-Band (802.11acabgn) WLAN + BT4.2 (BLE) module. This Combo Module is FCC, CE and IC certified and comes in extended temperature grade -30☌ to +85☌. The integrated Bluetooth 4.2 with LE specifications enables the new ecosystem of low energy Bluetooth Smart devices which can be tethered to the Smartphones and other consumer devices for new and emerging applications. This ultra-low power Wi-fi + BT combo module supports deep sleep and standby modes for low power operations.

The ultra-small form factor Multi-Band module, WM828CC6 gives Industry's Best in class performance for very high throughput (VHT), high transmit (Tx) power, excellent receive (Rx) sensitivity.

This Wifi plus Bluetooth co-ex module is a highly integrated subsystem that includes integrated MAC, baseband, RF front-end, PA, crystal, switch, filter and OTP memory for calibration data and MAC address storage and offers High speed SDIO 3.0 host interface for easy connection to all leading 32 bit processors running Linux operating systems. WM828CC6 from Wi2Wi's Maximum Performance series is a Hosted Dual-Band Wi-Fi (802.11 ac/a/b/g/n) and Bluetooth 4.2/BLE (Dual-Mode) Multi Protocol, Combo Module with integrated MHF4 IPEX connector.
